Purpurschlange®

Drinktel Butyl (fluidtel)

Beer and Beverage hose

High diffusion density pressure hose for beer, beverages, and a variety of non-fatty food products, with optimum resistance at higher pressures. Dimension tolerances according to ISO 1307.

For use in the brewing and beverage industries. Suitable for conveying beer and soft drinks. Meets BfR recommendation XXI, FDA (21 CFR 177.2600).

Inner layer: BIIR, white, phthalate free

Printing substrate: Synthetic textile inserts

Outer layer: Smooth, red, fabric patterned, abrasion, aging and ozone resistant

Temperature range: –40 °C to +120 °C

Dimensions: 25 / 32 / 40 / 50 / 65 / 75 / 100 mm (Inner Ø)



–> PDF (Drinktel Butyl)

Request this product

* Mandatory fields

Benefit from our hose production!

Individual hose systems for every application

You are not sure which hose fits your application?

We will assemble the right hose line for you with perfectly matched components. The hoses and fittings are professionally integrated and assembled according to current standards. Tested and certified on request.

Challenging fabrications for individual operational applications as well as different connection techniques are our specialty.

Do you need more detailed information for your possibilities of your own hose assembly? Contact us, we will advise you in detail!
